Steam Deck LCD

APU
6 nm AMD APU
CPU: Zen 2 4c/8t, 2.4-3.5GHz (up to 448 GFlops FP32)

GPU:
8 RDNA 2 CUs, 1.6GHz (1.6 TFlops FP32)

APU power:
4-15W

RAM
16 GB LPDDR5 on-board RAM (6400 MT/s quad 32-bit channels)

Both include high-speed microSD card slot

Controls and Input
Gamepad controls
A B X Y buttons
D-pad
L & R analog triggers
L & R bumpers
View & Menu buttons
4 x assignable grip buttons

Thumbsticks
2 x full-size analog sticks with capacitive touch
Haptics
HD haptics
Trackpads
2 x 32.5mm square trackpads with haptic feedback
Pressure-sensitivity for configurable click strength

Gyro
6-Axis IMU

Display:
LCD: 7", 1280 × 800 touchscreen IPS LCD (215ppi) @ 60 Hz, 400 nits
Response time
<0.1 ms
Touch enabled
High performance touch
Sensors
Light
Dual ambient light sensor ALS

Connectivity:
Bluetooth
Bluetooth 5.3 (support for controllers, accessories and audio)
Dedicated bluetooth antenna
Wi-Fi
Tri-band Wi-Fi 6E radio, 2.4GHz, 5GHz, and 6GHz 2 x 2 MIMO, IEEE 802.11a/b/g/n/ac/ax

Audio
Stereo with embedded DSP for an immersive listening experience
Microphones
Dual microphone array
Headphone / mic jack
3.5mm stereo headphone / headset jack
Digital
Multichannel audio via DisplayPort over USB-C, standard USB-C, or Bluetooth 5.3

Power Input
PD3.0 Type C power supply, 45W
2.5m cable

Battery
50Whr battery. 3-12 hours of gameplay

Expansion:
microSD
UHS-I supports SD, SDXC and SDHC

External connectivity for:
Controllers & Displays
Display port over Type C; up to 8K @60Hz or 4K @120Hz, USB3 gen 2


Size:
298mm x 117mm x 49mm

Weight:
Approx. 640 grams

Operating System
SteamOS 3 (Arch-based)
Desktop
KDE Plasma
